Advantage

• Accuracy unaffected by fluid density, viscosity, temperature, pressure, or conductivity.

• No obstructing parts, no pressure loss.

• Simple construction, easy installation, minimalstraight pipe section required.
• No mechanical inertia, fast response, goodlinearity, suitable for pulsating flow.
• Sensor lining and electrodes contact themedium; proper materials ensure corrosionand wear resistance for long-term use.
• Multi-electrode design for high accuracy, nogrounding ring needed, reducing costs.
• EEPROM stores specs and total flow dataduring power off.
• The transmitter utilizes low-powerconsumption single-chip microcomputer, withreliable performance, high accuracy, andstable zero. Dot-matrix LCD displays totalflow, instant flow, flow velocity, flow percentage.

• Two-way measurement, supports positive andnegative flow; low-frequency excitationimproves stability and low-flow performance

• Integrated pressure measurement, simultaneous flow and pressure reading

Features

Diameter	Flanged DN3 ～ DN2400
	Hygienic DN6 ～ DN50
	Threaded DN6 ～ DN50
	Wafer DN10 ～ DN300
Accuracy	Class 0.5, 0.2
Electrode types	Standard fixed electrode, anti-fouling electrode
	DN6 ～ DN20 one pair of measuring electrodes, no grounding electrode
	DN25 ～ DN500 one pair of measuring electrodes and one pair of grounding electrodes
	≥DN600 two pairs of measuring electrodes and one pair of grounding electrodes
Construction types	Integral, remote (remote cable length ≤ 99m)
Explosion-proof mark	Ex db ib mb IIC T6 Gb
Rated pressure	GB: PN2.5, PN6, PN16, PN25, PN40, PN63, PN100, PN160, PN250, PN320
	ANSI: CLASS 150, CLASS 300, CLASS 600, CLASS 900, CLASS 1500
	DIN: PN10, PN16, PN25, PN40, PN63, PN100
	JIS: 5K, 10K, 16K, 20K, 30K, 40K, 63K
	Others: Custom-made
Electrode	316L, Titanium (Ti), Hastelloy (HB, HC), Tantalum (Ta), Tungsten carbide (WC), Platinum -iridium (Pt), Ceramic
Lining	Chloroprene rubber (CR), Natural rubber (NR), Polyurethane rubber (PU)
Lining	Polytetrafluoroethylene (PTFE), F46, PFA, Ceramic
Meter tube	304 SS
Flange and body	Carbon steel, 304 SS, 316L SS
Transmitter housing	Cast aluminum, 304 SS
Power supply	220VAC
	12V DC, 24V DC
	Battery-powered (with LCD display, RS485 output, wireless output, frequency/pulse output – frequency/pulse output for calibration only)
Output signal	4mA ～ 20mA DC (load resistance 0Ω ~ 750Ω, active output)
	HART output
	Frequency/pulse output (optional passive or active)
	Upper and lower limit alarm output
	RS485 output (ModBus protocol), RS232 output
	Profibus-DP, Profibus-PA
Electrical port	M20×1.5 (Female), NPT 1/2 (Female)
IP rating	IP65: Dust proof, protected against water jets IP67: Dust proof, protected against temporary immersion IP68: Protected against continuous immersion (sensor part only, transmitter IP65), suitable for installation in instrument wells
Ambient temperature	-20℃~ 60℃ (optional -40℃~ 60℃)
Storage temperature	-40℃~ 60℃
Relative humidity	5%～90%
